BD Tubing Elevator

API Spec 8C Specification

Rated onus range ex 40 ton ad 75 ton
Cover tubings ab 1.9' ad 4½' OD

Quantity:
Availability:





inquire Add to Basket

BD Obfirmo Ring Typus Tubing Elevator API 8A/8C oilfield BD Tubing elevator

Product Description

Morbi condimentum

Tubing elevator ordinatur et fabricatur in linea cum API Spec 8C ¡° Specificatio ad Drilling et productionem Equipment¡± levantis, et elevator Tubing praesto esse potest cum exemplaribus DD, TA exemplaribus et BDA exemplaribus. In Sinis vel Russia, CD et BD, elevatores Tubing saepe petuntur. exempla DD, TA exempla et BDA exempla tubing elevatorum centrum pessuli elevatoris sunt, cum CD Tubing elevator latus est exemplar portae, BD elevator tubing peculiaris tubing elevator designator et popularis in Sinis est.

BD Tubing elevator est speciale genus collaris elevatoris ad tractandum operandi tubing in oleo et gasis exercendis, BD elevatores Tubing ex alto qualitate mixturae ferri, caloris af

BD Tubing elevatores simpliciter duae figurae tantum sunt, pro plano Tubing, BD elevator Tubing cum uno cincinno annulo offertur, dum pro EU Tubing, anulus elevator duplex cincinnus offertur, et duplex cincinnus elevator ad campum et EU Tubing accomodare potest. Commodum BD Tubing elevatoris leve est in pondere et vili pretio ac facile in operatione.

Specification	Tubing spec		Elevator bore		opus onus
	Tubing spec		Top	Bottom	opus onus
	in	mm	mm	mm	ton
BD 50 (1.9)	1.9	48.26	50.39	50.39	40 65 75
BD 56(1.9EU)	1.9EU	48.26	55.96	55.96
BD 63(2⅜)	2⅜	60.33	62.31	62.31
BD 68(2⅜EU)	2⅜EU	60.33	68.66	68.66
BD 76(2⅞)	2⅞	73.03	75.01	75.01
BD 82(2⅞EU)	2⅞EU	73.03	81.36	81.36
BD 92(3½)	3½	88.9	90.88	90.88
BD 98(3½EU)	3½EU	114.3	98.02	98.02
BD 104 (4).	4	101.6	103.58	103.58
BD 110(4EU)	4EU	101.6	110.72	110.72
BD 117(4½)	4½	114.3	116.66	116.66
BD 123(4½EU)	4½EU	114.3	123.42	123.42

Description for BD Tubing elevator
SN	Descriptio	Qty
1	Corpus	1
2	Cincinno anulum	1
3	Link obstructionum	1
4	Palpate	3
5	Ver	1
6	Bolt	1
7	Screw	1
Princeps accentus area BD Tubing elevator
